Teltonika PR1KCN40 5G Combo Mobile/GNSS SMA Antenna
Teltonika PR1KCN40 5G Combo Mobile/GNSS SMA Antenna
SKU:NHT-PR1KCN40
The Teltonika PR1KCN40 is a dual-purpose 5G combo antenna designed for IoT and cellular applications. Featuring integrated mobile MIMO and GNSS capabilities, UV-resistant construction, and IP67 ingress protection, it delivers reliable connectivity for industrial and remote deployments.
Couldn't load pickup availability
- See our return policy
- 24 months Manufacturer Warranty
Product Information
| Brand | Teltonika |
|---|---|
| Category | IoT / LTE |
| SKU | NHT-PR1KCN40 |
| Availability | In Stock |
Overview
- The Teltonika PR1KCN40 is a professional-grade combo antenna engineered for demanding IoT and cellular applications. It combines a four-port 5G mobile MIMO antenna with an integrated GNSS receiver in a single, compact housing, eliminating the need for separate antenna installations and reducing cable complexity.
Designed for industrial durability, the antenna features an IP67-rated, UV-resistant enclosure rated for operation between -40 °C and +80 °C. The mobile section supports multiple cellular standards across the 600 MHz to 5 GHz spectrum, whilst the GNSS element includes an integrated low-noise amplifier (LNA) for precise positioning and timing applications. The 3-metre pre-attached cable and flexible M6 screw or adhesive mounting options simplify field deployment.
Ideal for IoT gateways, industrial routers, and remote monitoring systems, the PR1KCN40 reduces installation costs and improves reliability in applications where both cellular connectivity and location data are essential.
Specifications
| Manufacturer | Teltonika |
|---|---|
| Model | PR1KCN40 |
| Antenna Type | 5G Combo Mobile/GNSS |
| Mounting Type | M6 Screw or Adhesive |
| Enclosure Material | PC/PC+ABS |
| UV Resistant | Yes |
| Ingress Protection Rating | IP67 |
| RoHS Compliant | Yes |
| Cable Length | 3000 mm |
| Weight | 450 g |
| Operating Temperature | -40 °C to +80 °C |
| Operating Humidity | ≤ 90% |
| Mobile MIMO Antenna Frequency Range | 600–960 MHz, 1427–2700 MHz, 3300–4200 MHz, 4400–5000 MHz |
| Mobile Polarisation | Linear |
| Mobile Radiation Pattern | Omni-directional |
| Mobile Gain | ≤ 4 dBi |
| Mobile V.S.W.R | ≤ 2.5 |
| Mobile Impedance | 50 Ω |
| Mobile Connector Type | 4 x SMA Male |
| Mobile Cable Type | 4 x LMR100 |
| GNSS Frequency Range | 1559–1610 MHz, 1164–1189 MHz |
| GNSS Polarisation | RHCP (Right-Hand Circular) |
| GNSS Radiation Pattern | Directional |
| GNSS Gain | ≤ 2 dBi |
| GNSS LNA Gain | 17 ± 2 dB |
| GNSS LNA Noise Figure | ≤ 2 dB |
| GNSS V.S.W.R | ≤ 2 |
| GNSS Impedance | 50 Ω |
| GNSS Supply Voltage | 3–5 VDC |
| GNSS Current Consumption | 15 mA |
| GNSS Connector Type | 1 x SMA Male |
| GNSS Cable Type | 1 x LMR100 |
| Warranty | 24 months |
Key Features
Ideal For
FAQs
What networks does the Teltonika PR1KCN40 support?
The PR1KCN40 supports 5G and LTE across multiple frequency bands from 600 MHz to 5 GHz, including sub-6 GHz 5G, as well as legacy 2G, 3G, and 4G standards. It is backwards compatible with existing cellular networks.
Can I use this antenna for GPS and mobile connectivity simultaneously?
Yes. The antenna integrates both a mobile MIMO section (4 ports) and a dedicated GNSS section (1 port), allowing simultaneous cellular and positioning data transmission without interference.
What is the cable length and is it included?
The antenna comes with a 3-metre LMR100 cable pre-attached. The integrated LNA (Low-Noise Amplifier) for GNSS is built into this cable, delivering 17 dB of gain for improved positioning accuracy.
Is the PR1KCN40 suitable for outdoor use?
Yes. The antenna is rated IP67 for dust and water ingress, UV resistant, and rated for operation between -40 °C and +80 °C, making it suitable for harsh outdoor environments including extreme temperatures.
How is the antenna mounted?
The antenna can be mounted using either an M6 screw mount or adhesive application, providing flexibility for different installation scenarios on poles, rooftops, or equipment housings.
What is the impedance and connector type?
Both the mobile and GNSS sections are 50 Ω impedance. The mobile section has 4 x SMA Male connectors, and the GNSS section has 1 x SMA Male connector, all with LMR100 cable.
Is the antenna RoHS compliant?
Yes, the PR1KCN40 is fully RoHS compliant, meeting environmental and safety standards for use in Europe and other regulated markets.
