DeepCool PQ1000G 1000W Fully Modular ATX Power Supply
DeepCool PQ1000G 1000W Fully Modular ATX Power Supply
SKU:PSD-PQ1000G-GS
Couldn't load pickup availability
Product Information
| Brand | DEEPCOOL |
|---|---|
| Category | Power Supplies |
| SKU | PSD-PQ1000G-GS |
| Availability | Out of Stock |
Overview
- The DeepCool PQ1000G delivers 1000W of stable, efficient power for demanding computing environments. Its 80+ Gold and Cybenetics PLATINUM efficiency ratings ensure minimal energy waste, reducing operational costs and heat generation. The fully modular cable system provides flexibility for custom builds whilst maintaining a clean internal layout that optimises airflow and cooling.
Built with premium Japanese electrolytic capacitors and advanced DC-to-DC conversion topology, the PQ1000G offers robust protection against electrical faults through multiple safeguards including overvoltage, overcurrent, short-circuit, and thermal protection. The FDB cooling fan operates quietly under load, making it suitable for both performance-focused builds and noise-sensitive environments.
With an MTBF rating of 100,000 hours and a 10-year warranty, the PQ1000G is engineered for long-term reliability. Its compact dimensions and ATX12V V3.1 compliance make it compatible with standard case configurations, whilst its comprehensive certification portfolio meets international regulatory and environmental standards.
Specifications
| Total Output | 1000W |
|---|---|
| Type | ATX12V V3.1 |
| Efficiency Certification | 80+ Gold / Cybenetics PLATINUM / PPLP Gold |
| Efficiency at 50% Load | ≥90% |
| Fan Size | 120×120×25mm |
| Fan Bearing Type | FDB (Fluid Dynamic Bearing) |
| Topology | Active PFC + Half Bridge SRC LLC + DC to DC |
| Capacitors | Full Japanese Electrolytic |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms at full load |
| Protection Features | OPP / OVP / SCP / OTP / OCP / UVP / SIP / NLO |
| Operating Temperature | 0-40°C |
| MTBF | 100,000 hours |
| Dimensions | 150×140×86mm (W×L×H) |
| Regulatory Compliance | EAC |
| Environmental Standard | ErP 2013 |
| Cable Configuration | Fully modular |
Key Features
Ideal For
FAQs
What does 80+ Gold certification mean?
80+ Gold means the power supply converts at least 90% of input power to usable output at 50% load, with high efficiency across various load ranges. This reduces energy waste, lowers electricity costs, and minimises heat generation.
Is the DeepCool PQ1000G suitable for gaming PCs?
Yes. The 1000W capacity, fully modular cables, and silent FDB fan make it ideal for high-performance gaming builds. Its protection circuitry ensures stable power delivery to sensitive components.
What is FDB bearing technology?
FDB (Fluid Dynamic Bearing) uses oil film between moving parts to reduce friction and noise. It operates more quietly and reliably than traditional ball bearings, particularly under extended use.
Does the PQ1000G require any special installation?
No. It follows standard ATX form factor guidelines and fits most modern PC cases. The fully modular design allows you to connect only the cables you need, simplifying installation and cable management.
What does the 10-year warranty cover?
The 120-month (10-year) warranty covers defects in materials and workmanship. Specific coverage terms should be confirmed with your retailer, as warranty conditions may vary by region.
What protection features does the PQ1000G include?
It includes overvoltage protection (OVP), overcurrent protection (OCP), short-circuit protection (SCP), overtemperature protection (OTP), overpower protection (OPP), undervoltage protection (UVP), soft-start protection (SIP), and no-load operation protection (NLO).
