Mercusys MS106GP 6-Port Gigabit Desktop Switch with PoE+
Mercusys MS106GP 6-Port Gigabit Desktop Switch with PoE+
SKU:NWMS-MS106GP
The Mercusys MS106GP is a 6-port Gigabit desktop switch designed for small business networks and surveillance installations. Featuring 4-port PoE+ support up to 30W per port, isolation mode, and extended transmission up to 250m, it delivers reliable connectivity and flexible deployment for IT professionals.
Couldn't load pickup availability
- See our return policy
- 5 years Manufacturer Warranty
Product Information
| Brand | TP-LINK |
|---|---|
| Category | Network - Consumer |
| SKU | NWMS-MS106GP |
| Availability | In Stock |
Overview
- The Mercusys MS106GP is a compact 6-port Gigabit desktop switch purpose-built for small business networks and surveillance applications. With four dedicated PoE+ ports delivering up to 30W per port and a total power budget of 65W, it simplifies deployment of PoE-powered devices such as IP cameras, access points, and VoIP phones without requiring separate power infrastructure.
Isolation mode allows you to segment network traffic for specific ports, improving stability and security by keeping critical systems separate. The Extend Mode feature increases PoE transmission distance to 250 metres, making it ideal for surveillance setups and distributed office environments where devices are located far from the main switch.
Automatic PoE recovery reboots unresponsive or dropped devices without manual intervention, reducing downtime and improving network uptime. The metal casing provides efficient heat dissipation for reliable long-term operation in busy network environments.
Designed for ease of use, the MS106GP requires no configuration—simply connect devices and it begins working immediately. Backed by a 5-year warranty, it represents a dependable investment for growing businesses.
Specifications
| Ports | 6× Gigabit RJ45 ports |
|---|---|
| PoE Ports | 4× PoE+ ports |
| Power per PoE Port | 30W maximum |
| Total PoE Power Budget | 65W |
| Standards Compliance | IEEE 802.3af, IEEE 802.3at |
| Transmission Distance | Up to 250m with Extend Mode |
| Features | Isolation mode, PoE auto recovery, plug and play |
| Casing | Metal |
| Warranty | 5 years |
Key Features
Ideal For
FAQs
How many devices can the MS106GP power simultaneously?
The switch has 4 dedicated PoE+ ports with a total power budget of 65W. You can power multiple IEEE 802.3af/at compliant devices up to the 65W limit. For example, four 15W IP cameras or a combination of lower-power devices like access points and VoIP phones.
What is Extend Mode and when should I use it?
Extend Mode increases PoE transmission distance from the standard 100m to 250m. This is useful for surveillance systems, remote office locations, or outdoor installations where PoE-powered devices are located well beyond normal switching distances.
What does Isolation Mode do?
Isolation mode allows you to separate traffic on specific ports, preventing devices on isolated ports from communicating with each other. This improves network security and stability by keeping different systems (such as surveillance and office networks) logically separated.
Does the MS106GP require configuration or software?
No. The MS106GP is a plug-and-play device. Simply connect your devices to the ports and it begins operating immediately without any configuration, software installation, or management interface.
What is PoE auto recovery?
PoE auto recovery automatically reboots PoE-powered devices that become unresponsive or drop connection. This reduces downtime and eliminates the need for manual intervention to restore problematic devices.
Is the MS106GP suitable for surveillance systems?
Yes. With 4 PoE+ ports, support for IEEE 802.3af/at devices, extended transmission distance, and isolation mode capabilities, the MS106GP is well-suited for small to medium IP camera installations and NVR setups.
What warranty does the MS106GP include?
The MS106GP includes a 5-year warranty covering manufacturing defects and component failures.
