Simplecom CM501v2 HDMI to Component Video Converter
Simplecom CM501v2 HDMI to Component Video Converter
SKU:CBSI-CM501V2
The Simplecom CM501v2 is an HDMI to Component Video converter that transforms digital HDMI signals into analog YPbPr output with stereo audio. Supporting up to 1080p resolution, it bridges modern HDMI devices to legacy component displays and projectors with reliable, durable operation.
Couldn't load pickup availability
- See our return policy
- 12 months Manufacturer Warranty
Product Information
| Brand | Simplecom |
|---|---|
| Category | Cables |
| SKU | CBSI-CM501V2 |
| Availability | In Stock |
Overview
- The Simplecom CM501v2 provides a reliable, one-way conversion solution from modern HDMI sources to legacy component video systems. This is essential for organisations and venues operating mixed-generation display equipment, where newer devices must connect to older YPbPr projectors or monitors. The converter maintains full 1080p video quality whilst delivering clean stereo audio, making it ideal for professional installations, education facilities, and home theatre environments.
Built with a durable metal enclosure, the CM501v2 ensures stable operation in demanding environments with excellent thermal management. USB power input eliminates the need for additional power infrastructure, offering flexible deployment options. With HDMI v1.4 and HDCP 1.2 support, it maintains compatibility with current-generation source devices whilst serving as a bridge to legacy display technology.
Specifications
| Model | CM501v2 |
|---|---|
| Input Connection | HDMI v1.4 |
| Output Connections | Component (YPbPr) + R/L stereo audio |
| HDCP Support | HDCP 1.2 |
| HDMI Input Bandwidth | 1.65 Gbps / 165 MHz per channel |
| Total Bandwidth | 4.95 Gbps |
| Supported Video Resolutions | 480i, 576i, 480p, 576p, 720p, 1080i, 1080p |
| Vertical Frequency | 50/60 Hz |
| Audio Format Support | Uncompressed 2-channel LPCM |
| Case Material | Metal |
| Power Input | USB 5V / 1A |
| Maximum Power Consumption | 5W |
| Operating Temperature | 0°C to 70°C |
| Operating Humidity | 10% to 85% RH |
| Storage Temperature | −10°C to +80°C |
| Storage Humidity | 5% to 90% RH |
| Dimensions | 8.8 × 6.8 × 2.5cm |
| Weight | 68g |
| Warranty | 12 months |
| Package Contents | HDMI to Component Converter, HDMI Cable 0.5M, USB Power Cable, USB Wall Charger |
Key Features
Ideal For
FAQs
Can the CM501v2 convert component video back to HDMI?
No, the CM501v2 is a unidirectional converter that only converts HDMI to component video. It cannot be used in reverse.
What power supply does the converter require?
The CM501v2 is powered via USB 5V / 1A input. It can be powered using the included USB wall charger or any nearby USB port, offering flexible installation options.
What video resolutions does it support?
The converter supports 480i, 576i, 480p, 576p, 720p, 1080i, and 1080p resolutions, with a vertical frequency of 50/60 Hz.
Is audio output included?
Yes, the converter outputs both component video (YPbPr) and R/L stereo audio from the HDMI input, supporting uncompressed 2-channel LPCM audio.
What HDMI version is supported?
The CM501v2 supports HDMI v1.4 with HDCP 1.2 protection, ensuring compatibility with current HDMI source devices.
Is the converter suitable for professional installations?
Yes, the metal enclosure provides durability and excellent heat dissipation, making it suitable for professional AV installations, broadcast environments, and demanding operational settings.
What is included in the package?
The package includes the HDMI to Component Converter, a 0.5M HDMI cable, a USB power cable, and a USB wall charger for immediate use.
