Antec IM 360 ARGB 360mm Liquid Cooling Fan Kit
Antec IM 360 ARGB 360mm Liquid Cooling Fan Kit
SKU:CFA-IM360ARGB
The Antec IM 360 ARGB is a 360mm triple PWM fan kit designed for efficient liquid cooling systems. Featuring hydraulic bearings, addressable RGB lighting, and variable fan speeds from 800 to 1800 RPM, it delivers optimal thermal performance and visual customisation for high-performance PC builds.
Couldn't load pickup availability
- See our return policy
- 2 years Manufacturer Warranty
Product Information
| Brand | Antec |
|---|---|
| Category | Fan & Cooling Products |
| SKU | CFA-IM360ARGB |
| Availability | In Stock |
Overview
- The Antec IM 360 ARGB is a premium 360mm liquid cooling fan kit engineered for high-performance PC builds. It combines three hydraulic-bearing PWM fans with addressable RGB lighting, allowing users to manage both thermal performance and visual presentation from a single integrated solution.
The kit delivers impressive airflow of up to 134.43 CFM with variable speed control from 800 to 1800 RPM, enabling users to balance cooling performance against noise levels depending on system load. At maximum output, the fans produce only 32.8 dB, making them suitable for both performance and quieter builds.
Designed for liquid cooling systems, the IM 360 ARGB features a hydraulic bearing mechanism that extends fan lifespan to 40,000 hours while reducing vibration and mechanical noise. PWM control via a standard 4-pin connector gives users precise speed regulation, while the 3-pin LED connector integrates with RGB controllers for synchronised lighting effects.
Backed by a 2-year warranty and built to Antec's reliability standards, this fan kit is ideal for custom builders seeking a high-quality cooling solution that doesn't compromise on aesthetics or performance.
Specifications
| Fan Type | PWM Fan |
|---|---|
| Fan Configuration | Triple 360mm |
| Fan Speed Range | 800 to 1800 RPM |
| Airflow Range | 61.51 to 134.43 CFM |
| Air Pressure Range | 0.35 to 1.48 mmAq |
| Noise Level Range | 19.7 to 32.8 dB |
| Bearing Type | Hydraulic bearing |
| Lifespan | 40,000 hours |
| LED Type | Addressable RGB |
| Fan Connector | 4-pin PWM |
| LED Connector | 3-pin |
| Fan Rated Voltage | DC 12V |
| LED Rated Voltage | DC 5V |
| Fan Operating Voltage Range | DC 10.5 to 13V |
| LED Operating Voltage Range | DC 4.5 to 5.5V |
| Fan Rated Current | 0.5A |
| LED Rated Current | 1.4A |
| Dimensions | 364 x 124 x 28mm |
| Warranty | 2 years |
Key Features
Ideal For
FAQs
Is the Antec IM 360 ARGB compatible with my motherboard?
The IM 360 ARGB uses standard 4-pin PWM connectors for fan control and a 3-pin header for RGB lighting. It is compatible with most modern motherboards that feature PWM fan headers and addressable RGB (5V ARGB) headers. Check your motherboard manual to confirm availability of these connectors.
Can I control the RGB lighting independently?
Yes. The RGB lighting connects via a separate 3-pin addressable RGB (ARGB) header, allowing you to control colour and effects through compatible motherboard software or RGB controller software without affecting fan speed control.
What is the maximum noise level of these fans?
The Antec IM 360 ARGB produces a maximum noise level of 32.8 dB at full speed (1800 RPM). At lower RPM settings, noise levels drop to as low as 19.7 dB, making them suitable for both performance and silent builds.
How long do the hydraulic bearings last?
The hydraulic bearing design is rated for a lifespan of 40,000 hours of continuous operation, which equates to approximately 4.5 years of 24/7 use. Typical gaming and workstation use will extend this considerably.
Does this kit include a radiator?
The Antec IM 360 ARGB is a fan kit only and does not include a radiator. You will need to source a compatible 360mm radiator separately for your liquid cooling system.
What airflow can I expect at standard speeds?
The fan kit delivers variable airflow depending on RPM setting. At 800 RPM, airflow is approximately 61.51 CFM. At maximum speed (1800 RPM), it reaches 134.43 CFM, allowing you to find the balance between cooling performance and noise.
Is a warranty included?
Yes. The Antec IM 360 ARGB comes with a 2-year manufacturer warranty covering defects in materials and workmanship.
