TP-Link ES220GMP 20-Port Gigabit Managed Switch with PoE+
TP-Link ES220GMP 20-Port Gigabit Managed Switch with PoE+
SKU:NWTL-ES220GMP
The TP-Link ES220GMP is a 20-port Gigabit managed switch designed for small-to-medium business networks and IP surveillance deployments. Featuring 16-port PoE+, 250W power budget, and centralised cloud management, it delivers reliable connectivity and simplified network administration.
Couldn't load pickup availability
- See our return policy
- 5 years Manufacturer Warranty
Product Information
| Brand | TP-LINK |
|---|---|
| Category | Network - Consumer |
| SKU | NWTL-ES220GMP |
| Availability | In Stock |
Overview
- The TP-Link ES220GMP is a 20-port Gigabit managed switch purpose-built for business networks and surveillance deployments. With 16 PoE+ ports capable of delivering up to 30W each and a 250W total power budget, it simplifies infrastructure by consolidating power delivery and data connectivity into a single device.
Centralised management through the Omada cloud platform or web interface enables IT teams to configure, monitor, and troubleshoot the switch remotely. Features such as automatic loop prevention, VLAN support, and port isolation provide network segmentation and security, while QoS prioritisation ensures consistent performance across business-critical applications.
The switch is engineered for reliability in demanding environments. Its durable metal chassis withstands rack-mount installations, and extended PoE reach of up to 250m allows devices to be powered and connected further from the switch than traditional PoE implementations. Plug-and-play connectivity means minimal configuration is required for basic deployment, whilst advanced features are available for organisations needing greater control.
Specifications
| Ports | 16 × Gigabit PoE+ RJ45, 2 × Gigabit RJ45, 2 × Gigabit SFP |
|---|---|
| PoE Power Budget | 250W total |
| PoE Power Per Port | Up to 30W per PoE+ port |
| PoE Standards | IEEE 802.3af/at compliant |
| PoE Extended Reach | Up to 250m |
| Data Rate | Gigabit (1000 Mbps) |
| Management | Cloud-based (Omada), Web interface, Mobile app |
| Network Features | VLAN, IGMP Snooping, QoS, Automatic loop prevention, Port isolation, PoE auto-recovery |
| Physical Design | Metal casing, Rack-mountable |
| Warranty | 5 years |
Key Features
Ideal For
FAQs
How many PoE ports does the ES220GMP have?
The ES220GMP features 16 Gigabit PoE+ ports capable of delivering up to 30W each, plus 2 additional Gigabit RJ45 uplink ports and 2 Gigabit SFP ports for fibre connectivity.
What is the total power budget for PoE devices?
The switch has a total PoE power budget of 250W, allowing you to power multiple devices simultaneously. The maximum per-port power delivery is 30W.
Can I manage this switch remotely?
Yes. The ES220GMP supports centralised cloud-based management through the TP-Link Omada platform, accessible via web interface or the Omada mobile app from anywhere with internet access.
What is the maximum PoE transmission distance?
The ES220GMP supports extended PoE reach of up to 250m, allowing powered devices to be located further from the switch than standard PoE specifications.
Is this switch suitable for IP surveillance systems?
Yes. The combination of 16 PoE+ ports, extended reach, automatic loop prevention, and port isolation make it well-suited for IP camera deployments and surveillance networks.
Can I separate network traffic using this switch?
Yes. The ES220GMP supports VLAN configuration and port isolation, allowing you to segment network traffic for security and performance optimisation.
What warranty is included?
The TP-Link ES220GMP includes a comprehensive 5-year warranty covering defects in materials and workmanship.
Is rack mounting supported?
Yes. The switch features a durable metal casing and rack-mount design suitable for installation in standard data centre or network closet racks.
