APC Easy PDU Metered ZeroU 16A 230V 21-Outlet
APC Easy PDU Metered ZeroU 16A 230V 21-Outlet
SKU:UPA-EPDU2116M
The APC Easy PDU Metered ZeroU is a intelligent power distribution unit designed for data centre and server rack environments. Featuring real-time remote monitoring, 21 mixed outlets (18×C13, 3×C19), and zero rack space consumption, it delivers precise power management for Australian IT infrastructure.
Couldn't load pickup availability
- See our return policy
- 12 months Manufacturer Warranty
Product Information
| Brand | APC |
|---|---|
| Category | Data Racks & Accessories |
| SKU | UPA-EPDU2116M |
| Availability | In Stock |
Overview
- The APC Easy PDU Metered ZeroU EPDU2116M is a professional-grade power distribution unit built for Australian data centres and server environments. Its zero-U vertical mounting design preserves valuable rack space whilst delivering comprehensive power management capabilities.
With 21 mixed outlets and real-time metering, the PDU provides visibility into power consumption across connected equipment. Remote management via web interface, SNMP, and CLI allows IT teams to monitor loads, set thresholds, and receive alerts from anywhere – reducing downtime risk and improving operational efficiency.
The compact 56mm width makes it ideal for space-constrained installations, whilst the robust 3680 VA capacity handles typical enterprise server and networking loads. Support for 50/60 Hz operation and -5°C to +50°C ambient range ensures reliability across diverse Australian environments.
Firmware updates via network download ensure future compatibility and feature enhancements without requiring on-site replacement – lowering total cost of ownership for growing IT infrastructure.
Specifications
| Brand | APC |
|---|---|
| Manufacturer | Schneider Electric |
| Model | EPDU2116M |
| Product Type | Metered Rack PDU |
| Mounting Type | Vertical rack-mounted |
| Rack Units | 0U (zero rack space) |
| Input Voltage | 230V single phase |
| Input Current | 16A |
| Input Plug Type | IEC 60309 16A 2P+E |
| Output Voltage | 230V |
| Load Capacity | 3680 VA |
| Outlet Configuration | 18×IEC 60320 C13, 3×IEC 60320 C19 |
| Total Outlets | 21 |
| Network Frequency | 50/60 Hz |
| Height | 1400 mm |
| Width | 56 mm |
| Depth | 56 mm |
| Net Weight | 3.05 kg |
| Cord Length | 2.99 m |
| Number of Input Cables | 1 |
| Operating Temperature | -5°C to +50°C |
| Storage Temperature | -25°C to +65°C |
| Operating Humidity | 5% to 95% |
| Storage Humidity | 5% to 95% |
| Operating Altitude | 0 to 10,000 ft |
| Certifications | CE, UKCA |
| Management Features | Web interface, SNMP, Command Line Interface (CLI) |
| Additional Features | Real-time monitoring, overload detection, user-defined alarm thresholds, firmware upgrade capability |
| Colour | Black |
| Warranty | 12 months |
| Included Accessories | Installation guide, user manual, vertical mounting brackets |
Key Features
Ideal For
FAQs
What does 'Zero U' mean and why is it important?
Zero U means the PDU occupies zero rack units of vertical space. By mounting vertically on the side of a rack or enclosure, it preserves valuable U space for additional servers, switches, and other equipment – a critical consideration in space-constrained data centres.
Can I monitor power consumption remotely?
Yes. The EPDU2116M provides real-time remote power monitoring via web interface, SNMP, and Command Line Interface (CLI). You can access, configure, and manage the PDU from any location with network connectivity.
What is the maximum power capacity?
The PDU has a maximum load capacity of 3680 VA at 16A 230V input, making it suitable for typical enterprise server and networking equipment in a single rack.
What types of outlets does it have?
The EPDU2116M provides 21 mixed outlets: 18×IEC 60320 C13 outlets (standard server power connectors) and 3×IEC 60320 C19 outlets (high-power equipment connectors).
What happens if power load exceeds safe levels?
The PDU monitors power usage against user-defined alarm thresholds and alerts you to potential overload conditions. This allows you to redistribute loads or add capacity before equipment damage or downtime occurs.
Can firmware be updated without replacing the unit?
Yes. Firmware can be quickly and easily upgraded via network download, allowing you to benefit from future enhancements and features without replacing hardware already installed in the field.
Is the EPDU2116M suitable for Australian data centres?
Yes. It supports 230V single-phase input (standard in Australia), operates at 50/60 Hz, and is certified to CE and UKCA standards. Its operating temperature range of -5°C to +50°C covers typical Australian data centre and server room environments.
