APC EPDU2132SMBO Metered Switched Rack PDU 7.4kW
APC EPDU2132SMBO Metered Switched Rack PDU 7.4kW
SKU:UPA-EPDU2132SMBO
The APC EPDU2132SMBO is a metered switched rack PDU delivering 7.4kW across 24 outlets with individual outlet control and monitoring. Featuring advanced power management via EcoStruxure IT integration, environmental monitoring, and 1% metering accuracy, it provides critical power distribution for data centre infrastructure.
Couldn't load pickup availability
- See our return policy
- 24 months Manufacturer Warranty
Product Information
| Brand | APC |
|---|---|
| Category | Data Racks & Accessories |
| SKU | UPA-EPDU2132SMBO |
| Availability | Out of Stock |
Overview
- The APC EPDU2132SMBO is a professional-grade metered switched rack PDU designed for demanding data centre environments. With individual outlet switching and monitoring, it enables IT managers to control power distribution at the device level, preventing overloads and reducing downtime associated with equipment failures or power cycling needs.
Integration with EcoStruxure IT provides comprehensive power management capabilities through web, SNMP, and CLI interfaces, delivering enhanced cybersecurity and centralised infrastructure visibility. The 1% metering accuracy ensures precise power consumption tracking for billing, capacity planning, and energy optimisation.
Operating across a wide temperature range of -5°C to +50°C, the EPDU2132SMBO combines robust engineering with practical features including zero U vertical mounting, daisy-chain capability for network cost reduction, and environmental monitoring support. The lightweight aluminium design reduces installation effort whilst maintaining professional reliability backed by a 24-month warranty.
Specifications
| Brand | APC |
|---|---|
| Model | EPDU2132SMBO |
| Product Type | Metered Switched Rack PDU |
| Power Rating | 7.4kW |
| Input Voltage | 230V |
| Input Current | 32A |
| Input Connector | IEC60309 2P+E |
| Phase Configuration | Single phase |
| C13 Outlets | 20 |
| C19 Outlets | 4 |
| Total Outlets | 24 |
| Metering Accuracy | 1% (industry standard) |
| Outlet Control | Individual metered switching per outlet |
| Management Interface | Web, SNMP, Command Line Interface |
| Network Management Card | NMC3 |
| EcoStruxure IT | Compatible |
| Daisy-Chain Capability | Up to 4 PDUs on single IP address |
| Environmental Monitoring | Temperature and humidity sensor ports (sensors sold separately) |
| Mounting | Zero U vertical mounting (rack or enclosure) |
| Housing Material | Aluminium |
| Colour | Black |
| Power Cord Length | 3 m |
| Number of Power Cords | 1 |
| Operating Temperature Range | -5°C to +50°C |
| Cybersecurity Features | Secured interfaces, modified password policy |
| Warranty | 24 months |
| Included Documentation | Installation guide |
Key Features
Ideal For
FAQs
What is outlet-level metering and switching?
Outlet-level metering provides individual power consumption monitoring for each outlet, whilst switching allows remote on/off control of specific outlets. This enables IT teams to identify power-hungry equipment, prevent overloads, and remotely reboot locked-up devices without physical access to the data centre.
How does the EPDU2132SMBO integrate with EcoStruxure IT?
The integrated NMC3 Network Management Card connects the PDU to EcoStruxure IT via web, SNMP, or CLI interfaces. This provides centralised monitoring, alerts, and management of power distribution across your IT infrastructure.
Can I daisy-chain multiple PDUs?
Yes, up to 4 PDUs can be daisy-chained on a single IP address, reducing network infrastructure costs and simplifying management of large-scale power distribution.
What is the metering accuracy specification?
The EPDU2132SMBO provides 1% metering accuracy, an industry standard that ensures precise power consumption tracking for accurate billing, capacity planning, and energy management reporting.
Does the PDU support environmental monitoring?
Yes, the unit includes dedicated ports for external temperature and humidity sensors (sold separately), enabling environmental condition monitoring and compliance with data centre operational standards.
How does zero U mounting work?
Zero U vertical mounting allows the PDU to be installed alongside existing rack equipment without consuming a full rack unit, preserving valuable rack space for servers and other infrastructure.
What is included with the purchase?
The EPDU2132SMBO is supplied with a 3-metre power cord, IEC60309 inlet connector, and installation guide. A 24-month warranty covers the unit.
