DeepCool CH560 DIGITAL White Mid-Tower ATX Case
DeepCool CH560 DIGITAL White Mid-Tower ATX Case
SKU:CAD-CH560-DIG-WH
The DeepCool CH560 DIGITAL is a high-airflow mid-tower ATX case designed for gamers and system builders. Featuring a digital status display, magnetic hybrid mesh front panel, and three pre-installed 140mm ARGB fans, it delivers excellent cooling performance and modern aesthetics for custom PC builds.
Couldn't load pickup availability
- See our return policy
- 12 months Manufacturer Warranty
Product Information
| Brand | DEEPCOOL |
|---|---|
| Category | Cases & Accessories |
| SKU | CAD-CH560-DIG-WH |
| Availability | In Stock |
Overview
- The DeepCool CH560 DIGITAL is a modern mid-tower ATX case engineered for builders who prioritise airflow and aesthetics. Its digital status display sets it apart from traditional cases, providing real-time system information at a glance. The magnetic hybrid mesh front panel balances high airflow with effective dust management, whilst the three pre-installed 140mm ARGB fans ensure immediate cooling performance without additional investment.
With support for ATX, Micro-ATX, Mini-ITX, and E-ATX motherboards, the CH560 DIGITAL offers exceptional flexibility for various build sizes. The case accommodates up to four storage drives, extensive radiator options (including 360mm configurations), and graphics cards up to 380mm in length, making it suitable for demanding gaming and workstation builds.
The tempered glass side panel showcases internal components whilst maintaining structural integrity, and the spacious 458×230×471mm interior provides ample room for cable management and component installation. With 12 months warranty coverage, the CH560 DIGITAL represents a reliable foundation for high-performance custom systems.
Specifications
| Product Dimensions | 458×230×471mm (L×W×H) |
|---|---|
| Net Weight | 7.5kg |
| Materials | ABS, SPCC steel, tempered glass |
| Motherboard Support | Mini-ITX, Micro-ATX, ATX, E-ATX |
| Front I/O Ports | 1× USB 3.0, 1× USB Type-C, 1× audio jack |
| Storage Drive Bays | 2× 3.5-inch, 3× 2.5-inch (2 internal + 1 external) |
| Expansion Slots | 7 slots |
| Pre-Installed Fans | Front: 3× 140mm ARGB; Rear: 1× 120mm ARGB |
| Front Fan Support | 3× 120mm or 3× 140mm |
| Top Fan Support | 3× 120mm or 2× 140mm |
| Rear Fan Support | 1× 120mm or 1× 140mm |
| PSU Shroud Fan Support | 2× 120mm |
| Radiator Support | Front: 120/140/240/280/360mm; Top: 120/140/240/280/360mm; Rear: 120/140mm |
| CPU Cooler Height Limit | 175mm |
| GPU Length Limit | 380mm |
| Power Supply Compatibility | ATX PS2 (maximum length 170mm) |
| Warranty | 12 months |
Key Features
Ideal For
FAQs
What size motherboards does the CH560 DIGITAL support?
The CH560 DIGITAL supports Mini-ITX, Micro-ATX, ATX, and E-ATX motherboards, providing flexibility for various build configurations.
How many fans come pre-installed?
The case includes 4 pre-installed ARGB fans: three 140mm fans on the front and one 120mm fan on the rear. All are ARGB-equipped for synchronised lighting.
What radiator sizes can I install?
The CH560 DIGITAL supports radiators up to 360mm on the front and top panels, and up to 140mm on the rear, making it suitable for comprehensive water-cooling builds.
How many storage drives can the case hold?
The case accommodates up to 4 storage drives: two 3.5-inch drives and three 2.5-inch drives (two internal bays plus one external bay).
What is the maximum GPU length supported?
The CH560 DIGITAL supports graphics cards up to 380mm in length, accommodating most modern high-end GPUs.
Does the case include a power supply?
No, the case does not include a power supply. It requires a separate ATX PS2 power supply with a maximum length of 170mm.
What are the front I/O connectivity options?
The front panel includes one USB 3.0 port, one USB Type-C port, and one audio jack for convenient front-panel connectivity.
