MSI Cubi NUC 5 12M-200BAU Mini PC Barebone i7-1255U
MSI Cubi NUC 5 12M-200BAU Mini PC Barebone i7-1255U
SKU:SYM-CUBI51MA623BAU
The MSI Cubi NUC 5 12M-200BAU is a compact mini PC barebone powered by Intel Core i7-1255U and Intel Iris Xe Graphics. With support for up to 64GB DDR4 memory, dual storage options, and Thunderbolt 4 connectivity, it delivers powerful performance in a space-saving form factor ideal for business and professional environments.
Couldn't load pickup availability
- See our return policy
- 36 months Manufacturer Warranty
Product Information
| Brand | MSI |
|---|---|
| Category | Systems - NUC/SFF/AIO |
| SKU | SYM-CUBI51MA623BAU |
| Availability | Out of Stock |
Overview
- The MSI Cubi NUC 5 12M-200BAU is a powerful mini PC barebone system designed for organisations requiring a compact, upgradeable computing platform. Featuring a 12th Gen Intel Core i7-1255U processor and Intel Iris Xe Graphics, it delivers professional-grade performance whilst occupying minimal desk or mounting space. The system supports up to 64GB of DDR4 memory and dual storage drives, making it suitable for demanding workloads including video editing, 3D design, and data analysis.
With Thunderbolt 4, DisplayPort 1.4, and HDMI 2.0 connectivity, this mini PC supports up to three simultaneous displays—enabling enhanced productivity for multi-tasking professionals. Built-in Intel Wireless AX211 and dual Gigabit Ethernet ports provide flexible networking options for both office and mobile deployments.
As a barebone system, it ships without an operating system, allowing you to install Windows 11 Pro or Home based on your requirements. MSI recommends Windows 11 Pro for business use. The included 65W power adapter and compact VESA mounting options make it suitable for traditional desks, wall mounts, or integrated solutions. Backed by a 36-month warranty, it offers reliability and peace of mind for mission-critical applications.
Specifications
| Processor | Intel Core i7-1255U (12th Gen) |
|---|---|
| Processor Generation | 12th Generation |
| Graphics | Intel Iris Xe Graphics |
| Chipset | Intel SoC |
| System Memory Type | DDR4 2666/3200MHz SO-DIMM |
| System Memory Maximum | 64GB (2x SO-DIMM slots) |
| Storage Drive 1 | 1x M.2 SSD (NVMe PCIe Gen4 x4 / SATA auto switch) |
| Storage Drive 2 | 1x 2.5" HDD/SSD |
| Operating System | No OS included; supports Windows 11 Home and Windows 11 Pro |
| USB Ports Front | 2x USB 3.2 Gen 2 Type A |
| USB Ports Rear | 2x USB 3.2 Gen 2 Type A |
| Thunderbolt Ports | 1x Thunderbolt 4 (USB Type C) front |
| Audio | 1x Mic-in/Headphone-out combo jack |
| Display Outputs | 1x HDMI 2.0, 1x DisplayPort 1.4 |
| Maximum Display Support | Three displays simultaneously (supports 8K UHD) |
| Network Ports | 2x Gigabit Ethernet RJ45 (1x Realtek RTL8111H, 1x Realtek RTL8125BG-CG) |
| Wireless LAN | Intel Wireless AX211 |
| Bluetooth | Bluetooth 5.3 |
| Cooling | Fan cooler |
| Power Supply | 65W AC adapter |
| Dimensions | 124 x 124 x 53.7mm (W x D x H) |
| Weight | 0.55kg net / 1.4kg gross |
| VESA Mount | 100 x 100mm / 75 x 75mm compatible |
| Management | MSI Center (system diagnosis and device management) |
| Warranty | 36 months |
| Included Accessories | Power adapter, power cord, user manual, quick guide, warranty card, VESA mount screws |
Key Features
Ideal For
FAQs
Is this a complete system or barebone?
This is a barebone system, meaning it comes without an operating system, RAM, or storage drives pre-installed. You will need to purchase and install Windows 11 (Home or Pro), RAM modules, and storage drives separately. MSI recommends Windows 11 Pro for business use.
Can I upgrade the memory and storage?
Yes. The system has 2x DDR4 SO-DIMM slots supporting up to 64GB total, and two storage bays: one M.2 NVMe slot (PCIe Gen4) and one 2.5" SATA bay. Both are user-upgradeable.
How many displays can I connect?
The MSI Cubi NUC 5 supports three simultaneous displays via HDMI 2.0, DisplayPort 1.4, and Thunderbolt 4. It is certified for 8K UHD display output.
What is Thunderbolt 4 and why do I need it?
Thunderbolt 4 is the fastest connection standard available, delivering up to 40Gbps throughput. It supports high-bandwidth peripherals like external storage, video interfaces, and displays, making it ideal for professionals working with large files or requiring multiple external devices.
What are the networking options?
The system includes dual Gigabit Ethernet ports (RJ45) and Intel Wireless AX211 (Wi-Fi 6) with Bluetooth 5.3, providing both wired and wireless connectivity options.
Is this suitable for video editing or CAD work?
Yes. The Intel Core i7-1255U processor and Intel Iris Xe Graphics are capable of handling professional workloads including video editing, 3D design, and content creation, particularly when paired with sufficient RAM and fast NVMe storage.
What warranty is included?
The MSI Cubi NUC 5 includes a 36-month manufacturer warranty covering hardware defects and failures.
Can this be wall-mounted?
Yes. The system supports VESA mounting in both 100 x 100mm and 75 x 75mm configurations, making it compatible with most monitor arms and wall mounts. Mounting screws are included.
