Gigabyte B850 A ELITE WF7 AMD AM5 Motherboard
Gigabyte B850 A ELITE WF7 AMD AM5 Motherboard
SKU:MBG-B850AELITEWF7
The Gigabyte B850 A ELITE WF7 is an AMD AM5 motherboard designed for high-performance computing builds. Featuring DDR5 support up to 256 GB, PCIe 5.0 connectivity, Wi-Fi 7, and comprehensive storage options, it delivers reliability and expansion for IT professionals and system integrators.
Couldn't load pickup availability
- See our return policy
- 36 months Manufacturer Warranty
Product Information
| Brand | Gigabyte |
|---|---|
| Category | Motherboards |
| SKU | MBG-B850AELITEWF7 |
| Availability | In Stock |
Overview
- The Gigabyte B850 A ELITE WF7 is a feature-rich AMD AM5 motherboard engineered for demanding computing environments. Based on the AMD B850 chipset, it supports the latest Ryzen 9000, 8000, and 7000 series processors with full backward compatibility, providing a solid foundation for current and next-generation systems.
Memory and storage capabilities are extensive: four DDR5 DIMM slots accommodate up to 256 GB of system memory with support for AMD EXPO and XMP profiles, while three M.2 connectors and four SATA ports provide flexible storage configuration. PCIe 5.0 support on compatible processors enables maximum bandwidth for graphics cards and NVMe SSDs.
Connectivity is comprehensive with Wi-Fi 7 (Realtek RTL8922AE), 2.5 GbE Ethernet, and multiple USB 3.2 ports including Gen 2x2 Type-C. RAID support for both NVMe and SATA drives adds data resilience options. With its 36-month warranty, this motherboard is ideal for system integrators, content creators, and IT professionals requiring a reliable, expandable platform.
Specifications
| Brand | Gigabyte |
|---|---|
| Model | B850 A ELITE WF7 |
| Chipset | AMD B850 |
| CPU Socket | AMD Socket AM5 |
| Supported Processors | AMD Ryzen 9000, 8000, and 7000 series |
| Memory Slots | 4 x DDR5 DIMM |
| Maximum Memory | 256 GB (64 GB per module) |
| Memory Speed Support | DDR5 8200 MHz (O.C) down to 4400 MHz |
| Memory Profiles | AMD EXPO, XMP |
| Memory Architecture | Dual channel |
| PCIe Slots | 3 x PCI Express x16 (1 x PCIe 5.0 x16 CPU-integrated on compatible CPUs, 2 x PCIe 3.0 x1 from chipset) |
| M.2 Connectors | 3 x M.2 Socket 3 (M key), supporting 25110/22110/2580/2280 form factors |
| M.2 Storage Speed | PCIe 5.0 x4/x2 (CPU-integrated on Ryzen 9000/7000), PCIe 4.0 x4/x2 (Ryzen 8000) |
| SATA Connectors | 4 x SATA 6 Gbps |
| RAID Support | RAID 0, 1, 5 (Ryzen 9000 only), 10 for NVMe; RAID 0, 1, 10 for SATA |
| Onboard Graphics | Integrated AMD Radeon Graphics (CPU-dependent) |
| Video Outputs | 1 x DisplayPort 1.4 (up to 3840x2160@144 Hz), 1 x HDMI 1.4 (1920x1080@30 Hz) |
| Network Interface | Realtek 2.5 GbE LAN (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless | Realtek Wi-Fi 7 RTL8922AE |
| USB (Back Panel) | 1 x USB 3.2 Gen 2 Type-C, 2 x USB 3.2 Gen 2 Type-A, 1 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0/1.1 |
| USB (Internal Headers) | 1 x USB 3.2 Gen 2x2 Type-C, 2 x USB 3.2 Gen 2 Type-A, 3 x USB 3.2 Gen 1 Type-A, 8 x USB 2.0/1.1 |
| Total USB 3.2 Ports | 9+ (including internal headers) |
| Form Factor | ATX |
| Warranty | 36 months |
Key Features
Ideal For
FAQs
Which AMD Ryzen processors are compatible with the Gigabyte B850 A ELITE WF7?
The motherboard supports AMD Ryzen 9000, 8000, and 7000 series processors. For the complete and latest CPU support list, consult Gigabyte's official website.
What is the maximum memory capacity supported?
The motherboard supports up to 256 GB of DDR5 memory via four DIMM slots, with a maximum of 64 GB per module. Both AMD EXPO and XMP memory profiles are supported.
Does this motherboard support PCIe 5.0?
Yes. The primary PCIe x16 slot supports PCIe 5.0 x16 on AMD Ryzen 9000 and 7000 series processors. Ryzen 8000 series support is limited to PCIe 4.0. The secondary slots support PCIe 3.0.
How many M.2 slots does it have, and what speeds do they support?
The motherboard features 3 x M.2 slots. Two are CPU-integrated supporting PCIe 5.0 x4/x2 (Ryzen 9000/7000) or PCIe 4.0 (Ryzen 8000). One chipset-integrated slot supports PCIe 4.0 x4/x2.
Does the B850 A ELITE WF7 support RAID?
Yes. It supports RAID 0, 1, 5 (Ryzen 9000 only), and 10 for NVMe SSDs, and RAID 0, 1, and 10 for SATA drives.
What wireless and networking options are included?
The motherboard includes Wi-Fi 7 (Realtek RTL8922AE) and a 2.5 GbE Ethernet interface supporting 2.5 Gbps, 1 Gbps, and 100 Mbps connectivity.
How many USB ports are available?
The motherboard provides 9+ USB 3.2 ports across the back panel and internal headers, including USB 3.2 Gen 2x2 Type-C, Gen 2 Type-A, and Gen 1 ports, plus USB 2.0/1.1 connectors.
What warranty is provided with this motherboard?
The Gigabyte B850 A ELITE WF7 includes a 36-month warranty.
