Gigabyte B860M A ELITE WIFI6E Micro-ATX Motherboard
Gigabyte B860M A ELITE WIFI6E Micro-ATX Motherboard
SKU:MBG-B860MAELITEWF6E
The Gigabyte B860M A ELITE WIFI6E is a micro-ATX motherboard for Intel Core Ultra processors. With PCIe 5.0 support, Wi-Fi 6E connectivity, and quad-display capability, it delivers high-speed performance and future-proof expandability for business workstations and high-performance builds.
Couldn't load pickup availability
- See our return policy
- 36 Months Manufacturer Warranty
Product Information
| Brand | Gigabyte |
|---|---|
| Category | Motherboards |
| SKU | MBG-B860MAELITEWF6E |
| Availability | Out of Stock |
Overview
- The Gigabyte B860M A ELITE WIFI6E is a feature-rich micro-ATX motherboard built on the Intel B860 chipset, designed to support 15th generation Intel Core Ultra processors via LGA1851 socket. This board combines modern connectivity standards with expandable storage and memory options, making it suitable for business workstations, professional applications, and performance-oriented builds.
With PCIe 5.0 support on the primary expansion slot, organisations can future-proof their investments in high-speed storage and peripherals. The integrated Intel Wi-Fi 6E module ensures modern wireless performance, while quad-display capability via USB4, DisplayPort 2.1, and HDMI ports supports multi-monitor productivity setups without requiring additional graphics cards.
The motherboard supports up to 256GB of DDR5 memory across four DIMM slots with XMP profile compatibility, and includes three M.2 slots for flexible NVMe SSD configurations. Eight USB 3.2 ports plus additional USB2.0 headers provide comprehensive peripheral connectivity for enterprise and professional environments. Built-in RAID support (RAID 0, 1, 5, 10) enables data redundancy and performance optimisation for SATA-based storage systems.
Specifications
| Chipset | Intel B860 Express |
|---|---|
| Socket Type | LGA1851 |
| Processor Support | Intel Core Ultra Processors (15th Generation) |
| Form Factor | Micro-ATX |
| Memory Slots | 4 x DDR5 DIMM |
| Maximum Memory | 256GB (64GB per DIMM) |
| Memory Speed Support | DDR5 5600 to 9200 MT/s (DDR5-9200 O.C.) |
| Memory Architecture | Dual Channel |
| Memory Profiles | XMP, ECC Un-buffered DIMM (1Rx8/2Rx8), Non-ECC Un-buffered DIMM (1Rx8/2Rx8/1Rx16) |
| PCIe Slot 1 | 1 x PCIe 5.0 x16 (CPU Direct, supports x16) |
| PCIe Slot 2 | 1 x PCIe 4.0 x16 (Chipset, runs at x4) |
| M.2 Slot 1 | 1 x M.2 Socket 3 (2280, PCIe 5.0 x4/x2) - CPU Direct |
| M.2 Slot 2 | 1 x M.2 Socket 3 (2280/2580, PCIe 4.0 x4/x2) - Chipset |
| M.2 Slot 3 | 1 x M.2 Socket 3 (2280/2580/25110/22110, PCIe 4.0 x4/x2) - Chipset |
| SATA Connectors | 4 x SATA 6Gb/s |
| RAID Support | RAID 0, RAID 1, RAID 5, RAID 10 |
| Network Interface | Realtek 2.5GbE LAN (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless | Intel Wi-Fi 6E AX211 (802.11ax) |
| USB4 Ports | 1 x USB4 Type-C (CPU Direct, supports DisplayPort and USB4) |
| USB 3.2 Gen 2 Type-A | 2 x USB 3.2 Gen 2 Type-A (back panel) |
| USB 3.2 Gen 2 Type-C | 1 x USB 3.2 Gen 2 Type-C (internal header) |
| USB 3.2 Gen 1 | 6 x USB 3.2 Gen 1 (4 back panel, 2 internal header) |
| USB 2.0 Ports | 8 x USB 2.0/1.1 (4 back panel, 4 internal header) |
| Video Output 1 | 1 x DisplayPort 2.1 (up to 3840x2160@144Hz) |
| Video Output 2 | 1 x HDMI 2.1 (up to 4096x2160@60Hz) |
| Video Output 3 | 1 x HDMI 1.4 Front Panel Header (up to 1920x1080@30Hz) |
| Video Output 4 | 1 x USB4 Type-C with DisplayPort (up to 3840x2160@144Hz) |
| Maximum Displays | 4 Simultaneous |
| Integrated Graphics | Intel HD Graphics (CPU-dependent) |
| Onboard Graphics Processor | Yes (Integrated in CPU) |
| Warranty | 36 Months |
Key Features
Ideal For
FAQs
What processors are compatible with the Gigabyte B860M A ELITE WIFI6E?
This motherboard supports Intel Core Ultra processors with LGA1851 socket (15th generation). For a complete list of compatible CPUs, refer to Gigabyte's official CPU support list on their website.
How much memory can this motherboard support?
The B860M A ELITE WIFI6E supports up to 256GB of DDR5 memory across four DIMM slots. Each slot supports individual modules up to 64GB. Supported speeds range from DDR5-5600 to DDR5-9200 MT/s with overclocking.
Does this motherboard support M.2 NVMe SSDs?
Yes, it includes three M.2 slots. The first slot (M2A_CPU) supports PCIe 5.0 and is directly connected to the CPU. The other two slots (M2Q_SB and M2N_SB) support PCIe 4.0 via the chipset, with support for various form factors including 2280 and 2580.
What wireless connectivity does this motherboard offer?
The motherboard features Intel Wi-Fi 6E (AX211) wireless module, providing modern 802.11ax connectivity alongside the built-in Realtek 2.5GbE wired network interface.
Can I connect multiple displays without a dedicated graphics card?
Yes, the integrated Intel HD Graphics supports quad-display output simultaneously via DisplayPort 2.1, HDMI 2.1, front HDMI header, and USB4 Type-C. This eliminates the need for a dedicated graphics card in office and productivity environments.
What storage RAID options are available?
The motherboard supports RAID 0, RAID 1, RAID 5, and RAID 10 for SATA storage devices, enabling data redundancy and performance optimisation for enterprise storage configurations.
Is this motherboard suitable for business and professional workstations?
Yes, the B860M A ELITE WIFI6E is designed for business workstations with its compact micro-ATX form factor, extensive connectivity, multi-display support, and high-speed expandability via PCIe 5.0 and DDR5.
What is the warranty period for this motherboard?
The Gigabyte B860M A ELITE WIFI6E comes with a 36-month manufacturer warranty, covering defects in materials and workmanship.
