Alloy AS1008-P 8 Port Unmanaged Gigabit PoE Switch
Alloy AS1008-P 8 Port Unmanaged Gigabit PoE Switch
SKU:NHA-AS1008-P
The Alloy AS1008-P is an unmanaged Gigabit PoE switch designed for small workgroups requiring power delivery to networked devices. Featuring 8 PoE+ ports with up to 30W per port, 150W total power budget, and IEEE 802.3at compliance, it delivers simple, cost-effective PoE capability for IP phones, wireless access points, and IP cameras.
Couldn't load pickup availability
- See our return policy
- 36 months (3 years) Manufacturer Warranty
Product Information
| Brand | Alloy |
|---|---|
| Category | Network - Consumer |
| SKU | NHA-AS1008-P |
| Availability | In Stock |
Overview
- The Alloy AS1008-P is an entry-level unmanaged Gigabit switch purpose-built for delivering power and data to networked devices over a single Ethernet cable. With 8 PoE+ ports and a 150W power budget, it supports typical PoE powered devices including IP phones, wireless access points, and IP video cameras without the complexity of managed switching.
Designed for plug-and-play deployment, the AS1008-P requires no configuration and features auto-sensing ports that adapt to any network topology. All ports support auto MDI/X, eliminating the need for crossover cables and simplifying installation in small workgroup environments.
The switch combines robust all-metal construction with flexibility—it operates as a desktop unit or mounts into a standard 19-inch rack using included brackets. With wirespeed 16 Gbps switching capacity and full IEEE 802.3at and 802.3af compliance, it delivers reliable performance for small to medium business networks requiring cost-effective PoE capability.
Specifications
| Number of Ports | 8 x RJ-45 Gigabit Ethernet |
|---|---|
| Port Speed | 10/100/1000 Mbps (Auto-sensing) |
| Switching Capacity | 16 Gbps wirespeed |
| PoE Standard | IEEE 802.3at and 802.3af compliant |
| Power per Port | Up to 30W (802.3at) |
| Total Power Budget | 150W |
| Power Supply | External power adapter |
| Auto MDI/X | Yes, all ports |
| Form Factor | Desktop with optional 19-inch rackmount brackets |
| Case Material | All-metal construction |
| Warranty | 36 months (3 years) |
Key Features
Ideal For
FAQs
What is the difference between IEEE 802.3at and 802.3af PoE standards?
IEEE 802.3af provides up to 15.4W per port, while 802.3at (PoE+) provides up to 30W per port. The AS1008-P supports both standards; each port can deliver up to 30W and is backward-compatible with 802.3af devices requiring less power.
Can I use the AS1008-P to power multiple devices simultaneously?
Yes. The switch has a total 150W power budget, allowing you to power multiple devices across the 8 ports. For example, you could power five 30W devices or eight 15-20W devices depending on your specific requirements.
Is the AS1008-P managed or unmanaged?
The AS1008-P is unmanaged, meaning it requires no configuration. Simply plug it in and connect your devices—it works immediately. There is no web interface, CLI, or VLAN management available.
What devices can I power with this switch?
The AS1008-P can power IEEE 802.3at and 802.3af compliant devices, including IP phones, wireless access points, IP video cameras, access control systems, and other PoE-compatible networked devices.
Can I rack-mount the AS1008-P?
Yes. The switch includes 19-inch rackmount brackets, allowing you to mount it in a standard equipment rack. It can also be used as a desktop unit without the brackets.
What is the warranty period for the AS1008-P?
The Alloy AS1008-P includes a 3-year manufacturer's warranty, covering defects in materials and workmanship.
Do I need to configure VLAN or QoS settings?
No. As an unmanaged switch, the AS1008-P automatically handles all traffic with no configuration required. It is ideal for simple plug-and-play deployments where advanced network management is not needed.
