Antec GSK850 Lite AU 850W ATX3.1 Power Supply
Antec GSK850 Lite AU 850W ATX3.1 Power Supply
SKU:PSA-GSK850-LITEAU-BULK
The Antec GSK850 Lite AU is an 850W ATX3.1 certified power supply designed for modern gaming and workstation builds. Featuring 80 Plus Gold efficiency, a silent 120mm fan, and comprehensive protection circuitry, it delivers reliable power and reduced running costs for demanding systems.
Couldn't load pickup availability
- See our return policy
- 5 years Manufacturer Warranty
Product Information
| Brand | Antec |
|---|---|
| Category | Power Supplies |
| SKU | PSA-GSK850-LITEAU-BULK |
| Availability | In Stock |
Overview
- The Antec GSK850 Lite AU is a robust 850W power supply engineered for modern computing demands. Certified to the latest ATX3.1 standard and compatible with PCIe 5.1 graphics cards, it ensures seamless integration with current and next-generation hardware platforms.
With 80 Plus Gold certification, this PSU operates at up to 92% efficiency, translating to lower electricity bills and reduced heat output. The PhaseWave™ LLC design with synchronous rectification provides the stable, clean power that demanding components require, whilst the comprehensive CircuitShield™ protection suite safeguards your system against electrical anomalies.
The silent 120mm HDB fan keeps noise levels minimal during operation, making it suitable for both enthusiast gaming rigs and professional workstations. Built with Antec's reputation for reliability and backed by a 5-year warranty, this non-modular design prioritises simplicity and durability over cable management flexibility.
Specifications
| Model | GSK850 Lite AU |
|---|---|
| Power Output | 850W |
| Type | ATX 12V 3.1 |
| Modular Design | Non-Modular |
| Efficiency Rating | 80 Plus Gold (up to 92%) |
| Input Voltage | 100V–240V |
| Input Current | 10A Max |
| Input Frequency | 50Hz–60Hz |
| Power Factor Correction | Active PFC |
| Power Good Signal | 100–150ms |
| Fan | 120mm HDB Silent Fan |
| Operating Temperature | 0–40°C |
| Dimension | 150mm (L) × 140mm (W) × 86mm (H) |
| Weight | 2.10 kg (net) |
| Warranty | 5 years |
| Mainboard Connector | 1 × 24-pin (20+4) ATX |
| CPU Power Connectors | 2 × 8-pin (4+4) |
| PCIe Power Connectors | 1 × 16-pin (12+4) PCIe 5.1 12V-2×6, 3 × 8-pin (6+2) PCIe |
| SATA Connectors | 6 × SATA |
| Molex Connectors | 2 × Molex |
| Protection Features | OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO |
| Regulatory Certifications | cTUVus, CB, CE, FCC, ICES |
Key Features
Ideal For
FAQs
Is the Antec GSK850 Lite AU compatible with modern graphics cards?
Yes. The PSU includes a PCIe 5.1 12V-2×6 GPU cable and meets the ATX3.1 standard, ensuring full compatibility with next-generation graphics cards including RTX 40-series and AMD RDNA 3 models.
What does 80 Plus Gold efficiency mean?
80 Plus Gold means the PSU operates at up to 92% efficiency, converting more of your input power into usable output whilst generating less waste heat. This reduces electricity costs and lowers your system's environmental impact over time.
Why is this a non-modular power supply?
Non-modular means all cables are permanently attached. Whilst this requires more planning during cable routing, it eliminates connection points, improving reliability and reducing the risk of loose connections.
How quiet is the 120mm HDB fan?
The Antec GSK850 Lite AU uses a high-quality 120mm HDB (Hydrodynamic Bearing) fan designed for whisper-quiet operation. The larger fan diameter allows for lower RPM rotation, reducing noise whilst maintaining adequate cooling.
What protective features does CircuitShield™ include?
CircuitShield™ provides comprehensive industrial-grade protection: Over-Current Protection (OCP), Over-Voltage Protection (OVP), Under-Voltage Protection (UVP), Short-Circuit Protection (SCP), Over-Power Protection (OPP), Over-Temperature Protection (OTP), Surge Interval Protection (SIP), and No-Load Operation (NLO).
What is the warranty period?
The Antec GSK850 Lite AU comes with a 5-year manufacturer warranty, providing long-term peace of mind and reflecting Antec's confidence in the product's durability and reliability.
What is the power input requirement?
The PSU accepts input voltage from 100V to 240V at 50Hz–60Hz frequency, making it compatible with standard Australian mains power.
Is this PSU suitable for a gaming PC build?
Yes. With 850W capacity, ATX3.1 and PCIe 5.1 support, silent operation, and high efficiency, the GSK850 Lite AU is an excellent choice for high-performance gaming builds with modern components.
