Gigabyte Gaming 750GM PG5 Ice 750W 80+ Gold PSU
Gigabyte Gaming 750GM PG5 Ice 750W 80+ Gold PSU
SKU:CFGP-GME750GMPG5ICE
Couldn't load pickup availability
- See our return policy
- 36 months Manufacturer Warranty
Product Information
| Brand | Gigabyte |
|---|---|
| Category | Power Supplies |
| SKU | CFGP-GME750GMPG5ICE |
| Availability | In Stock |
Overview
- The Gigabyte Gaming 750GM PG5 Ice delivers 750W of stable power in a compact, efficient form factor. Purpose-built for modern gaming and high-performance computing, it combines 80+ Gold efficiency with cutting-edge ATX3.1 and PCIe 5.0 support. The unit features a quiet 135mm FDB fan and comprehensive protection circuitry to safeguard your components against electrical stress.
With dual EPS connectors, four PCIe 6+2 connectors, and a dedicated 16-pin PCIe 5.0 connector, it provides the power infrastructure needed for current and next-generation high-performance graphics cards and processors. The 90% efficiency rating minimises heat generation and operating costs, while the 100,000+ hour MTBF rating ensures long-term reliability for demanding workloads.
Fully modular cabling and sleek all-black design simplify cable management in modern PC cases. Backed by a comprehensive 3-year warranty, this unit is engineered for builders and IT professionals who demand both performance and dependability.
Specifications
| Power Output | 750W |
|---|---|
| Efficiency Rating | 80+ Gold |
| Efficiency at Typical Load | 90% |
| Form Factor | ATX 12V v3.1 |
| Dimensions | 150 × 150 × 86 mm |
| Fan Type | 135mm Fluid Dynamic Bearing (FDB) |
| Input Voltage | 100–240 VAC |
| Input Frequency | 50–60 Hz |
| Input Current | 10–5 A |
| Active PFC | Yes (>0.9 typical) |
| MTBF | >100,000 hours |
| Power Good Signal | 100–150 ms |
| Hold-Up Time | ≥17 ms (at 80% load) |
| Cable Type | Fully modular, embossed, all-black |
| ATX/Motherboard Connector | 20+4 Pin × 1 (610 mm) |
| CPU/EPS Connectors | 4+4 Pin × 2 (600 mm each) |
| PCIe 16-Pin Connector | 1 × 16-pin (700 mm) |
| PCIe 6+2 Pin Connectors | 4 × (600 mm + 150 mm variants) |
| SATA Connectors | 8 × (600 mm + 150 mm + 150 mm + 150 mm variants) |
| Peripheral 4-Pin Connectors | 4 × (500 mm + 150 mm + 150 mm + 150 mm) |
| Protection Features | OVP, OPP, SCP, UVP, OCP, OTP, NLO, SIP |
| Warranty | 36 months |
Key Features
Ideal For
FAQs
Is the Gigabyte Gaming 750GM PG5 Ice suitable for RTX 40 series graphics cards?
Yes. The unit features a dedicated 16-pin PCIe 5.0 connector and four 6+2 pin connectors, providing ample power for next-generation high-end graphics cards including RTX 4090 and RTX 4080 systems.
What does 80+ Gold certification mean?
80+ Gold means the power supply converts at least 90% of input power to usable output at 50% load, reducing wasted energy as heat. This improves efficiency, lowers electricity costs, and generates less heat.
What is the difference between modular and fully modular cabling?
Fully modular means all cables disconnect from the PSU, allowing complete freedom in cable management and easier case organisation. The Gigabyte Gaming 750GM PG5 Ice features fully modular cabling.
What protection systems does this power supply include?
It features comprehensive protection: OVP (Over-Voltage), OPP (Over-Power), SCP (Short-Circuit), UVP (Under-Voltage), OCP (Over-Current), OTP (Over-Temperature), NLO (No-Load Operation), and SIP (Surge/Inrush Protection).
Can this PSU handle dual CPU systems or workstation configurations?
Yes. The unit includes dual EPS 4+4 pin connectors, making it suitable for dual-socket workstations and high-core-count processor systems requiring additional power delivery.
How long is the warranty on the Gigabyte Gaming 750GM PG5 Ice?
The unit comes with a comprehensive 36-month (3-year) warranty covering manufacturing defects and component failures.
Is the 135mm fan loud during gaming?
The Fluid Dynamic Bearing (FDB) fan is engineered for quiet operation at typical loads. During gaming, the fan adjusts speed based on internal temperature, balancing cooling efficiency with noise levels.
