TP-Link TL-PA411 KIT AV500 Nano Powerline Adapter
TP-Link TL-PA411 KIT AV500 Nano Powerline Adapter
SKU:NWTL-PA411-KIT
The TP-Link TL-PA411 KIT is a compact AV500 powerline adapter starter kit designed for extending network coverage throughout your home. Featuring HomePlug AV compliance, 500Mbps data transfer, and a miniature design, it provides reliable connectivity with minimal power consumption.
Couldn't load pickup availability
- See our return policy
- 36 months Manufacturer Warranty
Product Information
| Brand | TP-LINK |
|---|---|
| Category | Network - Consumer |
| SKU | NWTL-PA411-KIT |
| Availability | In Stock |
Overview
- The TP-Link TL-PA411 KIT is a practical solution for extending network coverage throughout your home using your existing electrical wiring. This starter kit includes two nano-sized adapters that connect to standard power outlets, eliminating the need for additional cabling while maintaining reliable connectivity.
With HomePlug AV compliance, the adapters deliver up to 500Mbps data transfer rates across distances up to 300 metres within your home. The miniature form factor ensures they sit discreetly behind or beside furniture without creating unsightly bulges at power points.
Setup is straightforward: plug in both adapters, press the pairing button, and connect your device via the included Ethernet cable. The intelligent power-saving mode automatically reduces energy consumption during periods of low activity, addressing both operational costs and environmental concerns.
This kit is ideal for homeowners seeking reliable wired connectivity in areas where wireless coverage is weak or inconsistent, such as bedrooms, home offices, or entertainment zones.
Specifications
| Standard | HomePlug AV, IEEE 802.3, IEEE 802.3u |
|---|---|
| Data Rate | Up to 500Mbps |
| Modulation | OFDM |
| Encryption | 128-bit AES |
| Ethernet Interface | 1× 10/100Mbps |
| Range | 300 metres (in-house) |
| Power Consumption (Maximum) | 4.0W at 220V/50Hz |
| Power Consumption (Typical) | 3.2W at 220V/50Hz |
| Power Consumption (Standby) | 0.7W at 220V/50Hz |
| Plug Type | EU, UK, AU |
| LED Indicators | PWR, PLC, ETH |
| Dimensions (per unit) | 65 × 52 × 28.5mm (2.6 × 2.0 × 1.1 inches) |
| Operating Temperature | 0–40°C |
| Storage Temperature | −40–70°C |
| Operating Humidity | 10–90% non-condensing |
| Storage Humidity | 5–90% non-condensing |
| Certifications | CE, FCC, RoHS |
| Warranty | 36 months |
| Package Contents | 2× Powerline Ethernet Adapters, 1× Ethernet cable (RJ45), Resource CD, Quick Installation Guide |
| System Compatibility | Windows XP/2000/Vista/7/8, Mac, Linux |
Key Features
Ideal For
FAQs
How fast is the TP-Link TL-PA411 KIT?
The adapters support up to 500Mbps data transfer rates using the HomePlug AV standard. Actual performance depends on your electrical wiring quality and distance between adapters.
How far apart can the adapters be placed?
The TL-PA411 KIT has a maximum range of 300 metres within your home. Both adapters must be on the same electrical circuit for optimal performance.
Does the kit require any special setup or software?
No. The TL-PA411 KIT is plug-and-play. Simply insert both adapters into power outlets, press the pairing button, and connect your device via the included Ethernet cable. No software installation is required.
Is the connection secure?
Yes. Data transmitted between adapters is protected by 128-bit AES encryption, ensuring secure communication across your powerline network.
How much power does it consume?
Typical power consumption is 3.2W per adapter. The patented power-saving mode can reduce consumption by up to 85% during periods of low activity, minimising energy costs.
Can I use the kit across different rooms or floors?
Yes, provided both adapters are connected to the same electrical circuit. In homes with multiple circuits, performance may vary. Testing placement before permanent installation is recommended.
What's included in the starter kit?
The kit includes two TL-PA411 nano adapters, one RJ45 Ethernet cable, a resource CD, and a quick installation guide.
Is the miniature design less powerful than full-size powerline adapters?
No. The miniature design is purely aesthetic and does not compromise performance. It achieves the same 500Mbps data transfer rates and 300-metre range as larger models, while occupying minimal space at the power outlet.
