DeepCool PS750G WH 750W SFX Power Supply
DeepCool PS750G WH 750W SFX Power Supply
SKU:PSD-PS750G-WH
The DeepCool PS750G WH is a 750W SFX power supply designed for compact gaming and workstation builds. Featuring Cybenetics Platinum efficiency certification, Japanese electrolytic capacitors, and fluid dynamic bearing cooling, it delivers reliable, efficient power for space-constrained systems.
Couldn't load pickup availability
- See our return policy
- 5 years Manufacturer Warranty
Product Information
| Brand | DEEPCOOL |
|---|---|
| Category | Power Supplies |
| SKU | PSD-PS750G-WH |
| Availability | In Stock |
Overview
- The DeepCool PS750G WH is a premium 750W SFX power supply engineered for space-constrained high-performance systems. Its compact form factor (125 × 100 × 63.5mm) makes it ideal for small form factor builds without compromising on power delivery or efficiency.
Certified to Cybenetics Platinum and PPLP Gold standards, the PS750G WH achieves 90% efficiency at 50% load, minimising energy waste and heat generation. The unit features full Japanese electrolytic capacitors for superior reliability and longevity, backed by a 100,000-hour MTBF rating.
Thermal management is handled by a 92mm fluid dynamic bearing fan that operates quietly whilst maintaining optimal temperatures across demanding workloads. The active PFC and half-bridge SRC LLC topology deliver stable, regulated power across all rails, with comprehensive protection circuitry safeguarding connected components against overvoltage, overcurrent, overtemperature, and short-circuit conditions.
With a 5-year warranty and compliance with international regulatory standards (CE, CCC, TUV-RH, KC, RCM, EAC), the PS750G WH is a trusted choice for system integrators, enthusiasts, and businesses building compact, efficient computing systems.
Specifications
| Brand | DeepCool |
|---|---|
| Model | PS750G WH |
| Power Output | 750W |
| Form Factor | SFX12V V4.1 & ATX12V V3.1 |
| Dimensions | 125 × 100 × 63.5mm (W × L × H) |
| Weight | Not specified |
| Fan Size | 92 × 92 × 20mm |
| Fan Type | Fluid Dynamic Bearing (FDB) |
| Efficiency Rating | Cybenetics Platinum / PPLP Gold |
| Efficiency at 50% Load | ≥90% |
| Capacitors | Full Japanese Electrolytic |
| Topology | Active PFC + Half Bridge SRC LLC + DC to DC |
| Power Good Signal | 100–150ms |
| Hold-up Time | ≥16ms at 80% load |
| Protections | OPP, OVP, SCP, OTP, OCP, UVP, SIP, NLO |
| Operating Temperature | 0–40°C |
| MTBF | 100,000 hours |
| Certifications | CE, CCC, TUV-RH, KC, RCM, CAN ICES(B), NMB(B), EAC |
| Environmental Compliance | WEEE, RoHS, Triman, EAC RoHS |
| ErP Regulation | ErP 2014 |
| Warranty | 5 years |
Key Features
Ideal For
FAQs
Is the DeepCool PS750G WH suitable for small form factor builds?
Yes. The PS750G WH is specifically designed for SFF builds. At just 125 × 100 × 63.5mm, it fits most mini-ITX cases whilst delivering 750W of reliable power.
What efficiency certification does this power supply have?
The PS750G WH is certified to both Cybenetics Platinum and PPLP Gold standards. It achieves ≥90% efficiency at 50% load, minimising energy loss and heat output.
Does the fan run quietly?
Yes. The 92mm fluid dynamic bearing fan is designed for quiet operation whilst maintaining effective thermal management across typical workloads.
What protection features are included?
The PS750G WH includes eight protection circuits: overvoltage (OVP), overcurrent (OCP), overtemperature (OTP), short-circuit (SCP), overpower (OPP), undervoltage (UVP), soft-start (SIP), and no-load (NLO) protection.
What is the warranty period?
The PS750G WH includes a 5-year manufacturer's warranty covering defects in materials and workmanship.
Can this supply power both gaming systems and workstations?
Yes. The 750W capacity and comprehensive protection make it suitable for compact gaming PCs, workstations, and content creation systems requiring stable, efficient power.
Is this power supply compatible with standard ATX motherboards?
Yes. The PS750G WH supports both SFX12V V4.1 and ATX12V V3.1 standards, making it compatible with mini-ITX and some ITX motherboards.
