mbeat Tough Link USB-C to Mini DisplayPort Adapter
mbeat Tough Link USB-C to Mini DisplayPort Adapter
SKU:CBMB-MB-XAD-CMDPF
Couldn't load pickup availability
- See our return policy
- 12 months Manufacturer Warranty
Product Information
| Brand | MBEAT |
|---|---|
| Category | Cables |
| SKU | CBMB-MB-XAD-CMDPF |
| Availability | In Stock |
Overview
- The mbeat Tough Link USB-C to Mini DisplayPort Adapter provides reliable video connectivity for modern USB-C enabled devices. Supporting up to 4K resolution at 60Hz, it enables seamless connection to Mini DisplayPort displays, projectors, and external monitors without requiring additional drivers or software installation.
Designed for professionals and mobile workers, the compact 15cm cable and lightweight construction make it ideal for portable setups, presentations, and hot-desking environments. The adapter supports USB-C DisplayPort Alt-Mode, allowing simultaneous video output and USB power delivery from compatible devices.
Backward compatible with lower resolutions including 1080p, 720p, and 480p, the adapter works with a wide range of display equipment. Simply plug into any USB-C port with DisplayPort Alt-Mode support and connect to a Mini DisplayPort display to extend or mirror your screen instantly.
Specifications
| Host Interface | USB-C (Male) × 1 |
|---|---|
| Output Interface | Mini DisplayPort (Female) × 1 |
| USB-C Version | 3.2 Gen 2 |
| Mini DisplayPort Version | 1.2 |
| Maximum Resolution | 4K @ 60Hz (3840 × 2160) |
| Supported Resolutions | 4K@60Hz, 1080p, 720p, 480p |
| Cable Length | 15cm |
| Product Dimensions | 24 × 2 × 0.9cm |
| Product Weight | 19.2g |
| IC Chipset | C2119 |
| Warranty | 12 months |
| Compatible Devices | USB-C devices with DisplayPort Alt-Mode support; Mini DisplayPort displays, projectors, and game consoles |
Key Features
Ideal For
FAQs
Does this adapter support Thunderbolt displays?
No. While Thunderbolt 1 and 2 ports have the same physical shape as Mini DisplayPort, this adapter does not support Thunderbolt ports. Ensure your display has a dedicated Mini DisplayPort interface.
Will this adapter work with my USB-C laptop?
Yes, provided your laptop's USB-C port supports DisplayPort Alt-Mode for video output. Most modern laptops and tablets with USB-C have this capability, but verify your device specifications.
Can I use this adapter to connect to HDMI or VGA displays?
No. This adapter is designed exclusively for Mini DisplayPort outputs. To connect to HDMI or VGA displays, you will need a different adapter.
What resolutions does this adapter support?
The adapter supports 4K@60Hz (3840×2160) as the maximum resolution, with backward compatibility for 1080p, 720p, and 480p.
Is this adapter plug-and-play?
Yes. No drivers, software, or additional configuration is required. Simply connect the USB-C end to your device and the Mini DisplayPort end to your display.
Can I use this adapter for both video and charging simultaneously?
This adapter is designed for video output via DisplayPort Alt-Mode. For simultaneous charging and video, your device must support USB Power Delivery on the same USB-C port.
Is the 15cm cable length long enough?
The 15cm compact design is ideal for portable use and direct connections. For greater distances, consider using an extension cable or external display stand positioned closer to your device.
