Fanvil VIK-01 Complete Video Intercom Kit
Fanvil VIK-01 Complete Video Intercom Kit
SKU:IPF-VIK-01
The Fanvil VIK-01 is a complete video intercom system designed for villas and single-family homes. Featuring HD video calls, remote door unlocking, and multiple access methods including IC card, BLE, and mobile app control, it delivers comprehensive security and convenience for residential properties.
Couldn't load pickup availability
- See our return policy
- 24 months Manufacturer Warranty
Product Information
| Brand | Fanvil |
|---|---|
| Category | VOIP Phones |
| SKU | IPF-VIK-01 |
| Availability | Out of Stock |
Overview
- The Fanvil VIK-01 is a complete video intercom solution purpose-built for residential applications. The kit combines an i504W indoor station with a 7-inch touchscreen, an i60 video door phone with 2 MP camera, and the Fanvil Link mobile app, creating a fully integrated access and communication system.
The system supports multiple authentication methods—IC card, Bluetooth Low Energy (BLE), DTMF codes, and app-based controls—making it adaptable to various security requirements. The i60 door phone features a 140° wide viewing angle, infrared night vision, and IP65 weatherproofing, ensuring reliable performance in outdoor conditions ranging from −40 °C to +70 °C.
Remote door unlocking through the mobile app and SIP protocol integration allows residents to grant access from anywhere, while motion detection and tamper alarms provide additional security assurance. The indoor station's HD audio with echo cancellation and PoE compatibility simplifies installation and reduces wiring complexity.
Specifications
| Product Type | Video Intercom Kit |
|---|---|
| Kit Components | i504W indoor station, i60 video door phone, Fanvil Link mobile app |
| Indoor Station Model | i504W |
| Indoor Station Display | 7-inch capacitive touchscreen |
| Indoor Station Display Resolution | 1024 × 600 pixels |
| Indoor Station Housing | ABS casing, wall-mounted |
| Indoor Station Speaker | 2W with HD audio and AEC |
| Indoor Station Protocol | SIP 2.0 |
| Indoor Station Video Decoding | H.264/H.265 up to 1080p |
| Indoor Station Power Supply | 12 VDC/1 A or PoE 802.3af |
| Indoor Station Dimensions | 177.38 × 113.99 × 22.5 mm |
| Indoor Station Operating Temperature | −10 °C to +50 °C |
| Door Phone Model | i60 |
| Door Phone Camera | 2 MP CMOS |
| Door Phone Viewing Angle | 140° field of view |
| Door Phone Night Vision | Infrared support |
| Door Phone Access Methods | IC card, BLE, DTMF, remote unlock |
| Door Phone Relay | Built-in relay |
| Door Phone Motion Detection | Yes |
| Door Phone Tamper Alarm | Yes |
| Door Phone Panel Size | 50 × 130 × 30 mm |
| Door Phone Ingress Protection | IP65 |
| Door Phone Impact Protection | IK level rated |
| Door Phone Operating Temperature | −40 °C to +70 °C |
| Warranty Period | 24 months |
Key Features
Ideal For
FAQs
What's included in the Fanvil VIK-01 kit?
The kit includes the i504W indoor station with a 7-inch touchscreen, the i60 video door phone with 2 MP camera, and access to the Fanvil Link mobile app for remote management and communication.
Can I unlock the door remotely using my smartphone?
Yes. The Fanvil Link mobile app integrates with the system via SIP protocol, allowing you to unlock the door remotely from anywhere with an internet connection.
What access methods does the i60 door phone support?
The i60 supports IC card, BLE (Bluetooth Low Energy), DTMF (phone keypad codes), and remote app-based unlocking for flexible access control.
Is the outdoor door phone unit weather-resistant?
Yes. The i60 is IP65-rated for weatherproofing and operates in temperatures from −40 °C to +70 °C, making it suitable for outdoor installation in most Australian climates.
Does the system support PoE installation?
Yes. The i504W indoor station supports PoE 802.3af, simplifying installation by allowing power and data over a single Ethernet cable.
What video quality does the door phone provide?
The i60 features a 2 MP CMOS camera with 140° wide viewing angle, infrared night vision, and full HD (1080p) video decoding capability through H.264/H.265 support.
Does the system include motion detection and alarms?
Yes. The i60 door phone includes built-in motion detection, tamper alarm, and relay output for integration with other security systems.
What is the warranty period?
The Fanvil VIK-01 comes with a 24-month manufacturer warranty covering all kit components.
