TP-Link Sector Bridge 5 Omada 5 GHz Wireless Bridge
TP-Link Sector Bridge 5 Omada 5 GHz Wireless Bridge
SKU:NWTL-SECTOR-BRIDGE5
The TP-Link Sector Bridge 5 is a scalable wireless bridge designed for long-range indoor and outdoor connectivity. Featuring 867 Mbps throughput, 5 km range, and IP66 weatherproofing, it delivers reliable multipoint networking for distributed sites and remote endpoints across Australian businesses.
Couldn't load pickup availability
- See our return policy
- 3 years Manufacturer Warranty
Product Information
| Brand | TP-LINK |
|---|---|
| Category | Network - SMB |
| SKU | NWTL-SECTOR-BRIDGE5 |
| Availability | Out of Stock |
Overview
- The TP-Link Sector Bridge 5 is a high-performance 5 GHz wireless bridge purpose-built for scalable, long-range connectivity across indoor and outdoor environments. With support for up to 32 simultaneous bridges via TDMA technology, it enables reliable multipoint networking across multiple buildings, remote endpoints, and distributed sites without the need for expensive fibre or leased line infrastructure.
The bridge delivers consistent 867 Mbps throughput over distances up to 5 km, backed by powerful 16 dBi dual-polarised directional antennas and a 120° wide beamwidth for flexible deployment patterns. Its IP66-rated weatherproof enclosure, 6 kV lightning protection, and extended operating temperature range (-40 °C to +70 °C) ensure year-round reliability in harsh Australian outdoor conditions.
Deployment is straightforward thanks to app-guided visual alignment, DIP switch pairing, and flexible installation options including wall or pole mounting with integrated bubble level. Power is flexible—choose 802.3af PoE, 24V Passive PoE, or 12V DC depending on your infrastructure. Remote monitoring and management are available in both standalone mode and Omada SDN, enabling centralised oversight across your entire wireless network via Web UI or mobile application.
Specifications
| Brand | TP-Link |
|---|---|
| Model | Sector Bridge 5 |
| Product Type | Wireless Bridge |
| Frequency Band | 5 GHz |
| Data Rate | 867 Mbps |
| Maximum Range | 5 km (3.1 miles) |
| Antenna Type | 16 dBi dual-polarised directional |
| Antenna Beamwidth | 120° |
| Supported Bridges | Up to 32 via TDMA |
| Enclosure Rating | IP66 weatherproof |
| Lightning Protection | 6 kV |
| Operating Temperature Range | -40 °C to +70 °C |
| Power Input Options | 802.3af PoE, 24V Passive PoE (adapter included), 12V DC |
| Installation Options | Wall or pole mount |
| Management Modes | Standalone, Omada SDN |
| Management Interface | Web UI, mobile app |
| Warranty | 3 years |
Key Features
Ideal For
FAQs
What is the maximum distance the TP-Link Sector Bridge 5 can transmit?
The Sector Bridge 5 supports long-range 5 GHz connectivity up to 5 km (3.1 miles) using its 16 dBi directional antennas, making it suitable for campus networks and remote site connectivity.
How many bridges can be connected in a multipoint setup?
The Sector Bridge 5 supports up to 32 Flex Bridges via TDMA technology, enabling scalable point-to-multipoint deployments across multiple buildings and remote endpoints.
Is the Sector Bridge 5 suitable for outdoor installation?
Yes. The bridge features an IP66 weatherproof enclosure, 6 kV lightning protection, and operates reliably in temperatures from -40 °C to +70 °C, making it well-suited for Australian outdoor environments.
What power supply options are available?
The Sector Bridge 5 supports three power options: 802.3af PoE (Power over Ethernet), 24V Passive PoE (with adapter included), and 12V DC, providing flexibility for various installation scenarios.
Can the Sector Bridge 5 be managed remotely?
Yes. The bridge supports both standalone mode and Omada SDN (Software-Defined Networking) mode for centralised remote management and monitoring via Web UI or mobile application.
What is the warranty period?
The Sector Bridge 5 includes a standard 3-year manufacturer warranty covering defects in materials and workmanship.
How easy is deployment and alignment?
The Sector Bridge 5 features app-guided visual alignment assistance and instant speed testing to simplify long-distance setup. DIP switches enable simple pairing with minimal configuration complexity.
